Substation Automation Systems

Name: Substation Automation Systems
Brand: CTR MANUFACTURING INDUSTRIES PRIVATE LIMITED

Get a Price/Quote

MOQ : 1 Piece

Substation Automation Systems Specification

Connector Type
Screw Terminal

Operating Temperature
-10C to +55C

Insulation Material
PTFE/Polycarbonate

Overheating Protection
YES

Surface Finish
Powder Coated

Humidity %
Up to 95% RH

IP Rating
IP54

Mounting Type
Floor Mount

Shape
Rectangular

Efficiency
>98%

Feature
Real-Time Monitoring, Control & Protection

Power Factor
>0.95

Product Type
Substation Automation System

Application
Industrial / Utility Substation Automation

Protection Level
High

Frequency (MHz)
50 Hz

Rated Voltage
415 V

Energy Consumption
Low

Output Type
Digital/Analog

Color
Grey

Dimension (L*W*H)
1800 x 800 x 600 mm

Weight
120 kg

Phase
Three Phase

Size
Standard

Input Voltage
220-240 V AC

No Of Poles
3

Material
Mild Steel

Connection Type
Panel Mounted

Relay Type
Numerical Protection Relays

Ethernet Ports
2

SCADA Compatibility
Yes

Software Support
Vendor Proprietary & Open Protocols

Display Type
LCD Touch Screen

Remote Monitoring
Supported

System Expandability
Modular Design

Panel Door Type
Double Door

Cooling Type
Natural Air / Forced Air

Control Voltage
24V/48V DC

Communication Protocols
IEC 61850, Modbus, DNP3

Alarm System
Integrated, Audible/Visual

Time Synchronization
GPS/IRIG-B

Data Storage
Inbuilt, up to 32GB

Substation Automation Systems Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Ex-Works

Payment Terms
Cash on Delivery (COD), Cash Advance (CA)

Packaging Details
Appropriately packed

Main Domestic Market
All India

About Substation Automation Systems

Our esteemed clients can purchase from us premium quality Substation Automation Systems. In order to manufacture these systems, our team of seasoned professionals makes use of excellent grade components with the help of latest technology in adherence to the defined market standards of quality. The provided systems are used for monitoring various industrial processes and thus, save time and effort. Moreover, the offered Substation Automation Systems are available with us in different specifications as per the demand laid down by our customers at market leading prices.

Features :-

Maintenance free
Excellent functionality
Longer service life

Advanced Communication and Interoperability

Equipped with industry-standard protocols including IEC 61850, Modbus, and DNP3, this system effortlessly communicates with diverse devices and SCADA platforms. Dual Ethernet ports ensure reliable, high-speed connectivity, while support for vendor-proprietary and open protocols maximizes compatibility across automation projects.

Integrated Data Storage and Real-Time Monitoring

With up to 32GB of inbuilt data storage, all operational data, events, and alarms are securely logged for detailed analysis. Real-time monitoring via LCD touch screen and SCADA integration provides comprehensive oversight, supporting swift responses to any anomalies for enhanced operational continuity.

Exceptional Protection and Efficiency

Numerical protection relays, high insulation grade materials, and an advanced alarm system safeguard your equipment against faults, overheating, and environmental threats. The system operates efficiently at over 98% energy efficiency and is protected by a powder-coated, IP54-rated enclosure for reliable longevity.

FAQs of Substation Automation Systems:

Q: How does the Substation Automation System ensure reliable communication within substations?

A: The system supports prolific communication protocols like IEC 61850, Modbus, and DNP3, utilizing dual Ethernet ports for rapid data exchange. This architecture allows diverse devices and SCADA systems to interact seamlessly, ensuring efficient substation operation and future scalability.

Q: What process is followed for real-time monitoring and control in this automation system?

A: Real-time monitoring is achieved through an LCD touch screen interface, integrated SCADA compatibility, and remote access. All operational data is stored internally (up to 32GB), alarms are relayed via audible/visual signals, and users can quickly intervene or adjust settings as needed for optimal performance.

Q: When should the system be expanded or upgraded, and is it easy to do so?

A: Thanks to its modular design, system expansion is straightforward. Upgrades or expansions are recommended when operational demands increase or technology evolvessimply add modules or new devices without disrupting existing functionality.

Q: Where can this automation system be installed and what are its environmental tolerances?

A: Designed for industrial and utility substations, the unit is suited for harsh environments (operational temperature: -10C to +55C; humidity up to 95% RH). Its IP54-rated mild steel enclosure ensures dust and splash resistance, with floor-mounting for secure installation.

Q: How is equipment protected against faults, overheating, and environmental risks?

A: The system implements numerical protection relays, overheat protection, and an advanced alarm system. Construction materials like PTFE and polycarbonate offer high insulation, while the enclosures powder-coated finish enhances durability. Forced or natural air cooling keeps temperatures stable.

Q: What are the main benefits of using this Substation Automation System for industrial or utility applications?

A: Key benefits include real-time remote monitoring, robust fault protection, easy scalability, low energy consumption, and long-term reliability. Its standards compliance ensures longevity and simplifies integration with future solutions, making it an optimal choice for secure and efficient substation management.
