Electric Pallet Truck

Name: Electric Pallet Truck
Brand: CTR MANUFACTURING INDUSTRIES PRIVATE LIMITED

Get a Price/Quote

MOQ : 1 Piece

Electric Pallet Truck Specification

Wheel Type
Polyurethane

Forklift
Yes

Rotation Type
180-degree turning radius

Rack Capacity
Adjustable to requirement

Control System
Electronic control handle with emergency stop

Equipment Type
Electric Pallet Truck

Lifting Speed
Up to 30 mm/s

Features
Side battery removal, Built-in charger, Maintenance-free battery

Handle Type
Ergonomic with fingertip controls

Motor Type
AC drive motor

Condition
New

Lifting Capacity
2000 kg

Max. Lifting Load
2000 kg

Max. Lifting Height
200 mm

Power Source
Battery Operated

Power Consumption
1.5 kW

Voltage
24V DC

Feature
Easy operation, Low maintenance

Attributes
Rust proof, High durability

Electric Pallet Truck Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Ex-Works

Payment Terms
Cash on Delivery (COD), Cash Advance (CA)

Packaging Details
Appropriately packed

Main Domestic Market
All India

About Electric Pallet Truck

We are an unparalleled name in manufacturing and supplying a premium quality Electric Pallet Truck. Our product is manufactured using premium quality components that are procured from the certified vendors of the market. It is tested on different predefined quality parameters before its final delivery. This is widely used in different industries for lifting of heavy goods and pallets to a desired height. Our Electric Pallet Truck is supplied to clients within the assured time frame.

Electric Pallet Truck Features:

Energy efficient
Easy installation
Optimum performance

Electric Pallet Truck Technical Details:

Capacity : 1000
Total Lift : 190
Lowered fork length : 85
Fork length : 1150/1220
Travel speed with load : 3.8 km/h
Battery Volts : 24
Net Weight : 150

Specification

Model	CEP 1	CEP 2	CEP3
Capacity	2000	1400	2000
Total Lift	120	205	205
Lowered fork length	85	85	85
Fork length	1150 / 1220	1150 / 1220	1150 / 1220
Travel speed with load	4.5 km/h	4.5km/h	5.8 Km/h
Battery Volts	24	24	24
Net Weight	460	260	400

Efficient Heavy Lifting for Every Warehouse

This electric pallet truck is designed to handle demanding loads with ease, supporting up to 2000 kg at a maximum lifting height of 200 mm. Engineered with a sturdy steel frame and IP54-rated control box, it reliably operates in various environments. Its quiet operation (70 dB(A)) and rust-proof build make it suitable for indoor and outdoor use alike.

User-Friendly Controls and Safety Features

Equipped with an ergonomic handle, electronic control handle with emergency stop, parking brake, and horn, this pallet truck emphasizes operator safety and comfort. The AC drive motor and power-assisted steering allow precise, effortless movement, while side battery removal and built-in charger streamline maintenance tasks.

Versatility and Low Maintenance

This electric pallet truck accommodates various rack capacities with adjustable forks and a high-gradeability design (5% laden, 16% unladen). Its maintenance-free battery and electronic control system help reduce service intervals, ensuring cost-effective operation over long periods. With a robust construction and advanced features, it delivers consistent performance in warehouses across India.

FAQs of Electric Pallet Truck:

Q: How does the electric pallet truck improve material handling efficiency in warehouses?

A: The electric pallet truck streamlines material handling by enabling effortless movement and lifting of heavy loads up to 2000 kg. Its AC drive motor, electronic controls, and ergonomic design enhance operator productivity while reducing manual labor and risk of injury.

Q: What is the recommended process for charging the battery?

A: Simply connect the on-board automatic charger to a power source. The maintenance-free, sealed battery does not require any additional attention, and side battery removal allows for easy replacement or maintenance when necessary.

Q: Where can this pallet truck be used effectively?

A: Thanks to its IP54-rated control box, high-strength steel construction, and wide operating temperature range (-10C to +50C), this truck is suitable for warehouses, distribution centers, cold storage, and outdoor loading areas.

Q: When should regular maintenance checks be performed?

A: Although the maintenance-free battery and rust-proof components require minimal upkeep, it is advisable to inspect electronic controls, brakes, and wheels monthly to ensure optimal safety and performance.

Q: What safety features are included with this pallet truck?

A: Safety features include an electronic control handle with emergency stop, an electromagnetic braking system, a parking brake, ergonomic controls, a horn for alerts, and a polycarbonate wheel set for stability even at maximum loads.

Q: How is the lifting speed and gradeability managed in various conditions?

A: The lifting speed reaches up to 30 mm/s, and gradeability is 5% when loaded and 16% when unladen. The AC drive motor and power-assisted steering ensure stable performance on ramps and uneven surfaces, making it suitable for diverse warehouse layouts.

Q: What are the key benefits of using this electric pallet truck over manual alternatives?

A: Benefits include significantly reduced operator fatigue, faster material handling cycles, increased safety, minimal noise (70 dB(A)), and lower maintenance due to its robust, high-quality build and electronic systems. It is ideal for businesses looking to enhance operational efficiency and reliability.
